Electromagnetic Vibrators
Manufacturing vibrators and controllers for feeding, conveying and dosing applications.
Request a quote for your project
Controlled material feeding
An electromagnetic drive generates vibration in a spring-mounted mechanism. With a suitable chute and controller, the material feed rate can be adjusted to the application.
Application-specific selection
Particle size, bulk density, moisture and flowability affect feeding behaviour. Amplitude, controller, chute dimensions, moving load and mounting points are considered together.
Applications
Applications include nut and pulse feeding, pre-packaging dosing, filling and weighing systems, small screening tasks and controlled material conveying. Food-contact requirements and special materials are assessed separately.
We consider the vibrator and controller together
Our 2016 website archive included a separate controller-board page alongside electromagnetic vibrators. Fine and coarse vibration adjustment, different modes and opto-isolated power control were described then. Current options are confirmed for your project.
Application-specific vibration solutions
Product information comes from our previous website. Capacity, equipment and electrical compatibility are confirmed before ordering.
| Product | Supply | Technical specification | Application |
|---|---|---|---|
| Electromagnetic feeder | Confirmed for each application | 50 / 100 Hz selection, 0–10 V control | Feeding, conveying and dosing |
| Suspended vibration unit | 220 V / 50 Hz | 140 W, 1.8 mm stroke | Chutes, small sieves and vibration tables |
| FEM-0025 | 220 V AC / 50–60 Hz | 500 W, 2 A, flange mounting | Powder / granules, filling and weighing |
Product photos and catalogue
Frequently asked questions
What information helps us choose a product?
Tell us the material type, particle size, target feed rate, chute dimensions and mounting conditions.
Contact us
Share your production requirements and we will find a suitable solution together.
